Description:

Specifications:

Engine & Drive

• Engine: Ariens AX®
• Starting System: 120V Electric
• Steering: Auto-Turn
• Drive Type: Disc-O-Matic
• Speeds: 6 Forward / 2 Reverse

Tires

• Size: 16 in (40.6 cm)
• Type: Directional Snow Tread

Clearing Specs

• Clearing Width: 30 in (76.2 cm)
• Housing Height: 21 in (53.3 cm)
• Throwing Distance: 3 ft – 50 ft
• Chute Rotation: 2.5x Ice Drill
• Chute Turning Radius: 200°
• Deflector Control: In-Dash Lever

Auger & Impeller

• Stage Type: Two Stage
• Auger Type: Steel Serrated
• Auger Diameter: 14 in (35.6 cm)
• Impeller: Steel, 3 Blade
• Impeller Diameter: 14 in (35.6 cm)

Durability Features

• Skid Shoes: Steel Reversible
• Scraper Bar: Steel Adjustable
• Gear Case: Cast Iron

Dimensions

• Length: 58.3 in (148.1 cm)
• Width: 32.4 in (82.3 cm)
• Height: 45.5 in (115.6 cm)
• Weight: 258.1 lb

Warranties

• Product Warranty: 3 years (residential), 90 days (commercial)
• Gear Case Warranty: 5 years (consumer), 1 year (commercial)
